The JJ-100 Wafer Resist Stripper & Cleaner is a dedicated post-etching processing equipment for university IC fabrication teaching lines — it handles resist stripping and cleaning of etched wafers, with 2 functional tanks, corrosion-resistant materials, and user-friendly design, tailored for academic teaching and lab training.
Specification Item | Details |
Model Number | JJ-100 |
Application | Resist stripping & cleaning for etched wafers (university IC fabrication teaching line) |
Functional Tanks | 2 dedicated tanks (resist stripping tank + cleaning tank) |
Tank Material | PP (corrosion-resistant) |
Tank Size | 200mm × 200mm × 200mm |
Gas/Water Configuration | 1 air gun + 1 water gun + 1 DI water tap |
Waste Liquid Recovery | 1 unit (with automatic liquid level monitoring) |
Ventilation System | Top exhaust port (φ200mm, with manual pressure valve) |
Power Input | AC380V, 1KW |
Machine Dimensions (L×W×H) | 1200mm × 1050mm × 2000mm |
Machine Weight | 180KG |
1. Teaching Process AlignmentExclusively designed for post-etching steps of IC teaching wafer lines, filling the gap between etching and subsequent processes in student training
2. Corrosion-Resistant & PracticalPP tank material resists common stripping reagents; dual-tank design separates stripping and cleaning to avoid cross-contamination
3. Safe & Easy to Operate
Automatic liquid level monitoring (prevents reagent overflow)
Top exhaust system (removes volatile fumes, complying with lab safety standards)
Integrated gas/water tools (convenient for students’ hands-on operation)
4. Space-Saving Lab DesignCompact size fits university lab workbenches; built-in storage cabinet (below tanks) provides space for reagent tools
Package: 1 set of JJ-100 Wafer Resist Stripper & Cleaner (including 2 functional tanks, gas/water modules, and exhaust system)
Service: On-site installation (for teaching line integration) + operation training (for teachers/students) + 1-year warranty
